Custom private networks

You can isolate users, data, or code using custom private networks.

Every organization gets a default private network (6PN) and all the apps in that network can communicate privately using .internal domains. When you create a new app, you can choose to place it on a distinct custom 6PN within your organization. Apps on separate 6PNs can never communicate unless explicitly configured to do so.

When to use custom private networks

Custom private networks (6PNs) are a good solution for tenant isolation within a single organization. If you run a Something-as-a-Service platform on top of Fly.io, then you can create an app on a custom 6PN per customer for isolation. For example, you could have an app on a custom 6PN for each customer instance of your service, or for each customer running untrusted code on your platform. Customer Machines can communicate freely within their app (or between apps in their network), but won’t be able to reach Machines or apps on other 6PNs.

Depending on your requirements for billing and app management, separate organizations per customer might be a better option for tenant or client isolation. You can use unified billing to manage billing for multiple organizations, or have each organization billed separately.

Network names and IDs

Network names are unique within your organization. We permanently associate a network ID with the network name the first time you specify the name and we never re-use that network ID within your organization. If you specify an existing network name when you create an app, we place the app on the associated network.

If you destroy all the apps on a custom 6PN, the network technically still exists.

It’s a best practice to use a formula for naming custom 6PNs, especially if you’re going to have a lot of them or if you need to add more than one app to each custom 6PN. For example, customerID-network or appName-someID-network. Network names can have letters, numbers, and dashes, but must start with a letter.

Create a custom private network

You can’t add an existing app to a custom 6PN or change an app’s 6PN. An app can only exist in one 6PN.

Create a custom 6PN with the Machines API when you create an app with a POST /v1/apps request.

For example:

    curl -i -X POST \\
    -H "Authorization: Bearer ${FLY_API_TOKEN}" -H "Content-Type: application/json" \\
    "${FLY_API_HOSTNAME}/v1/apps" \\
  -d '{
      "app_name": "my-app-name",
      "org_slug": "personal",
      "network": "my-custom-network-name"
    }'



See the Machines API docs for more information about using the API.

Create a custom 6PN with flyctl when you create an app:

fly apps create <app name> --network <network name>

The fly apps create command creates an “empty” app with no Machines. You’ll need to manually create Machines for the app using flyctl or the Machines API.

Connect apps in different 6PNs

Private apps on different 6PNs can’t communicate without being explicitly configured to do so.

Public apps

If an app has a publicly reachable service, then apps on different 6PNs can reach that service using the public IP addresses.

Private apps with Flycast

You can use a Flycast private IPv6 address to expose an app on one 6PN to another 6PN; the app won’t be accessible via Flycast from its own network. When you assign the Flycast address, use the --network option to specify the name of the network from which requests will originate. For example:

fly ips allocate-v6 --private --network custom-network-name

Learn more about using Flycast.

Forward requests with the `fly-replay` response header

The fly-replay response header tells Fly Proxy to forward HTTP requests to another app or Machine in your organization. You can use fly-replay to deliver requests to customer apps or Machines on custom 6PNs without having to expose them publicly.

For example, you could receive HTTP requests on a public “router” app and then forward the requests to specific apps or Machines on different customer 6PNs. The customer apps need to have services configured to expose a port on which to receive the requests. Make sure the customer apps don’t have public IP addresses: apps created with the Machines API or with fly apps create don’t get public IPs by default, but most apps created with fly launch do.

Learn more about using the fly-replay response header.

Connect directly to Machines on custom 6PNs

As an administrator with a multi-tenant setup, you might need to troubleshoot customer issues. You can use flyctl’s networking commands to reach Machines on a customer’s 6PN within your organization, including:

fly ssh console --app <app name> or fly ssh console --machine <machine id> to SSH into an app Machine. See the fly ssh console docs.
fly ssh sftp commands to work with files on an app Machine. See the fly ssh sftp docs.
fly proxy <local:remote> [remote_host] --app <app name> to create a WireGuard tunnel to an app Machine. See the fly proxy docs.

Check which network an app or Machine is on

You can retrieve the network name for all apps in your organization and you can also verify that apps or Machines are on different networks by examining their private IPv6 addresses.

Get network names

Right now the only way to get an app’s network name is by listing all the apps in an organization with the Machines API.

GET /v1/apps?org_slug=<org name>

Example response:

    {
    "total_apps": 22,
    "apps": [
        {
            "id": "682kqp63x4k9d543",
            "name": "aged-cherry-366",
            "machine_count": 4,
            "network": "default"
        },
        {
            "id": "704e9387kyy13xgn",
            "name": "muddy-violet-667",
            "machine_count": 2,
            "network": "test-network"
        },
...



See the Machines API docs for more information about using the API.

Network ID embedded in private IPv6 addresses

Each 6PN is identified by a network ID, which is encoded into 32-bits of each private IPv6 address.

You can confirm whether two Machines are on different networks by comparing their private IPv6 addresses. You can get a Machine’s 6PN address in any of the following ways:

run fly machines list -a my-app-name
run fly machines status <machine id>
from the Machine’s FLY_PRIVATE_IP environment variable
list the Machines in an app or get a specific Machine config using the Machines API

All Fly.io private IPv6 addresses start with fdaa. The 32-bits following fdaa identify the 6PN. For example, the following addresses belong to Machines on different 6PNs:

Machine 1: fdaa:2:45b:a7b:174:db43:d3c6:2
Machine 2: fdaa:9:d844:a7b:e:33bd:e8b1:2

Machine 1’s network ID is embedded in :2:45b: and Machine 2’s network ID is embedded in :9:d844:.

Flycast addresses also include the network ID in the same 32-bit grouping. Run fly ips list to get an app’s private IPv6 address.

Learn about 6PN addresses in detail.
