Continuous Deployment with Fly.io and GitHub Actions

A man writing code on a vintage desktop computer

This guide works through setting up your app for continuous deployment to Fly.io from the app’s GitHub repository. You might also like our blueprint on deploying review apps with GitHub Actions.

You’ll start with an example application called go-example. It’s a simple, lightweight app that displays the Fly.io region that served the request.

The first section is a speed-run through the steps to make the go-example app automatically deploy to Fly.io from GitHub. The next section loops back for a longer look at each step.

Speed-run your way to continuous deployment

  1. Fork the go-example repository to your GitHub account.
  2. Clone the new repository to your local machine.
  3. Run fly launch --no-deploy from within the project source directory to create a new app and a fly.toml configuration file.
  4. Type y to when prompted to tweak settings and enter a name for the app. Adjust other settings, such as region, as needed. Then click Confirm Settings.
  5. Still in the project source directory, get a Fly API deploy token by running fly tokens create deploy -x 999999h. Copy the output, including the FlyV1 and space at the beginning.
  6. Go to your newly-created repository on GitHub and select Settings.
  7. Under Secrets and variables, select Actions, and then create a new repository secret called FLY_API_TOKEN with the value of the token from step 5.
  8. Back in your project source directory, create .github/workflows/fly.yml with these contents:

    name: Fly Deploy
    on:
      push:
        branches:
          - master    # change to main if needed
    jobs:
      deploy:
        name: Deploy app
        runs-on: ubuntu-latest
        concurrency: deploy-group    # optional: ensure only one action runs at a time
        steps:
          - uses: actions/checkout@v4
          - uses: superfly/flyctl-actions/setup-flyctl@master
          - run: flyctl deploy --remote-only
            env:
              FLY_API_TOKEN: ${{ secrets.FLY_API_TOKEN }}


    Note: The go-example’s default branch is master. If you’re using a different app, yours might be main. Change the branches value in the fly.yml file accordingly.

  9. Commit your changes and push them up to GitHub. You should be pushing two new files: fly.toml, the Fly Launch configuration file, and fly.yml, the GitHub action file.

Then the magic happens - The push triggers a deploy, and from now on whenever you push a change, the app will automatically be redeployed.

If you want to watch the process take place, head to the repository and select the Actions tab, where you can view live logs of the commands running.

A longer look at the deployment process

fly.toml and the repository

Step 1 is a simple GitHub Fork; there’s not a lot to say about that except that you need to do it, because you want control of the repository that you’re deploying from.

Step 2 is just cloning the repository to your local system so that you can edit and push changes to it.

Steps 3 and 4 create a new app on Fly.io and a fly.toml configuration file to go into the repository.

A note about fly.toml in repositories: Usually, when Fly.io ships examples, we avoid putting the fly.toml file in the repository by including fly.toml in the .gitignore file. And users should be creating their own fly.toml with the fly launch command. When using GitHub Actions though, you want your fly.toml in the repository so that the action can use it in the deployment process.

API tokens

Step 5 is about getting an API token. You can generate a deploy token to use to authorize a specific application. That’s what flyctl tokens create deploy -x 999999h gives you. Remember to copy the whole token from the output, including the FlyV1 and space at the beginning. For a more powerful token that can manage multiple applications, run flyctl auth token.

Steps 6 and 7 make your new token available to GitHub Actions that run against your repository. You’ll add the token as a secret in the repository’s settings. Under the Settings tab, go to Secrets and variables and select Actions. Click on the green “New repository secret” button, enter the name as FLY_API_TOKEN, and copy the token as the secret.

If you’d prefer an environment secret instead, then you need to list the environment you selected in your deploy step. For example:

deploy:
    name: Deploy app
    runs-on: ubuntu-latest
    environment: production

Building the workflow and deployment

Step 8 is the heart of the process, where you put in place a workflow. Now, GitHub has a UI which allows you to select and edit workflows, but you can also modify them as part of the repository. So you create .github/workflows/fly.yml - you’ll likely want to mkdir -p .github/workflows to quickly create the directories - and load up the file with a GitHub Action recipe.

GitHub Action recipe, line by line:

name: Fly Deploy

This sets the displayed name for the action.

on:
  push:
    branches:
      - master

When should this action be run. There’s lots of options but in this case, in response to any push to the repository’s master branch. If your repository uses a default branch other than master, such as main, then you should change that here.

jobs:
  deploy:
      name: Deploy app
      runs-on: ubuntu-latest
      concurrency: deploy-group

An action is made up of named jobs, in this case one job to deploy the application. The jobs run on a virtual machine. This section gives the “deploy” job the name “Deploy app” and tells GitHub Actions to run it on a virtual machine with the latest version of Ubuntu on it. Optionally, use the concurrency key with a custom group name to ensure that only one action runs at a time for that group.

The next part is to set up the steps needed to complete this job.

      steps:
        - uses: actions/checkout@v4

The first step is one of the built in Actions steps. The step uses the checkout@v4 action which checks out the repository into a directory on the virtual machine. You’re now ready to deploy.

        - uses: superfly/flyctl-actions/setup-flyctl@master
        - run: flyctl deploy --remote-only

This step uses the superfly/flyctl-actions action. This is a GitHub action created by Fly.io which wraps around the flyctl command. The wrapper is invoked with the deploy argument which will take over the process of building and moving the application to the Fly.io infrastructure. It uses the settings from the fly.toml file to guide it and uses the FLY_API_TOKEN to authorize its access to the Fly.io GraphQL API.

          env:
            FLY_API_TOKEN: ${{ secrets.FLY_API_TOKEN }}

This pulls the API token from GitHub’s secrets engine and puts it into the environmental variables passed to the action.

Step 9 pushes your two new files to the repository: fly.toml, the app configuration file, and fly.yml, the GitHub action file. The push triggers your first automatic deploy. The GitHub action now triggers a redeploy each time you push changes to your repo.

Conclusion and further reading

And that’s the deployment process. You can, of course, leverage the GitHub Actions environment to manage more intricate deployments, interact with other applications—say to send Slack messages on completion—or whatever else you can dream up.
