Anatomy of an Ecto migration

Fly.io runs apps close to users, by transmuting Docker containers into micro-VMs that run on our own hardware around the world. This post is part of the Safe Ecto Migrations series guide. If you just want to ship your Phoenix app, the easiest way to learn more is to try it out; you can be up and running in just a couple minutes.

This is part 1 in a 4-part series on designing and running Safe Ecto Migrations:

Ecto migrations are used to do the following:

  • Change the structure of the database, such as adding fields, tables, or indexes to improve lookups
  • Populating fields with modified data or new data.

In order for us to create and run safe Ecto migrations on our database, it is helpful to understand what is actually happening with the database. To do that, we'll dig deeper into how Ecto migrations work by looking both at the code being executed and the Postgres logs.

To generate a migration, we'll use run a mix task:

mix ecto.gen.migration create_test_table

Tip: If you're using Phoenix, you might consider mix phx.gen.schema which will generate a migration and also allows you to pass in fields and types. See mix help phx.gen.schema for more information.

This command will generate a file in priv/repo/migrations given the repo name of Repo. If you named it OtherRepo the file would be in priv/other_repo/migrations.

Let's look at that file:

defmodule MyApp.Repo.Migrations.CreateTestTable do
  use Ecto.Migration

  def change do

  end
end

Let's make some changes; how about we create a table that tracks a city's climate?

defmodule MyApp.Repo.Migrations.CreateTestTable do
  use Ecto.Migration

  def change do
    create table("test") do
      add :city,    :string, size: 40
      add :temp_lo, :integer
      add :temp_hi, :integer
      add :prcp,    :float

      timestamps()
    end
  end
end

Now that we have a migration, let's run it! Run mix ecto.migrate.

mix ecto.migrate
21:26:18.992 [info]  == Running 20210702012346 MyApp.Repo.Migrations.CreateTestTable.change/0 forward
21:26:18.994 [info]  create table test
21:26:19.004 [info]  == Migrated 20210702012346 in 0.0s

Inspect SQL

Understanding exactly what SQL commands are running is helpful to ensure safe migrations, so how do we see the SQL that is executed? By default, Ecto does not log the raw SQL. First, I'll rollback, and then re-migrate but with an additional flag --log-sql (or --log-migrations-sql in later versions) so we can see what actually runs.

mix ecto.rollback
21:29:32.287 [info]  == Running 20210702012346 MyApp.Repo.Migrations.CreateTestTable.change/0 backward
21:29:32.289 [info]  drop table test
21:29:32.292 [info]  == Migrated 20210702012346 in 0.0s
mix ecto.migrate --log-sql
21:29:36.461 [info]  == Running 20210702012346 MyApp.Repo.Migrations.CreateTestTable.change/0 forward
21:29:36.462 [info]  create table test
21:29:36.466 [debug] QUERY OK db=3.2ms
CREATE TABLE "test" ("id" bigserial, "city" varchar(40), "temp_lo" integer, "temp_hi" integer, "prcp" float, "inserted_at" timestamp(0) NOT NULL, "updated_at" timestamp(0) NOT NULL, PRIMARY KEY ("id")) []
21:29:36.467 [info]  == Migrated 20210702012346 in 0.0s

Ecto logged the SQL for our changes, but we're not seeing all the SQL that Ecto is running for the migration— we're missing the Ecto.Migrator SQL that manages the migration. To get these missing logs, I'll set Postgres to log everything and then tail the Postgres logs and re-run the migration:

LOG:  statement: BEGIN
LOG:  execute <unnamed>: LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE
LOG:  execute ecto_3: SELECT s0."version"::bigint FROM "schema_migrations" AS s0
LOG:  statement: BEGIN
LOG:  execute <unnamed>: CREATE TABLE "weather" ("id" bigserial, "city" varchar(40), "temp_lo" integer, "temp_hi" integer, "prcp" float, "inserted_at" timestamp(0) NOT NULL, "updated_at" timestamp(0) NOT NULL, PRIMARY KEY ("id"))
LOG:  execute ecto_insert_schema_migrations: INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2)
DETAIL:  parameters: $1 = '20210718204657', $2 = '2021-07-18 20:53:49'
LOG:  statement: COMMIT
LOG:  statement: COMMIT

Tip: In the latest version of Ecto, you can use the flag --log-migrator-sql instead of tailing Postgres logs.

Let's trace the code: when running migrations, Ecto executes these functions:

  1. Ecto.Migrator.run/4
  2. Ecto.Migrator.lock_for_migrations/4
  3. The adapter's lock_for_migrations implementation
  4. Wrapped in another transaction

Inside the transaction, the Ecto Postgres adapter obtains a SHARE UPDATE EXCLUSIVE lock of the "schema_migrations" table.

Why this lock is important: Systems at scale may have multiple instances of the application connected to the same database, and during a deployment all of the instances rolling out may try to migrate that database at the same time, Ecto leverages this SHARE UPDATE EXCLUSIVE lock as a way to ensure that only one instance is running a migration at a time and only once.

This is what the migration actually looks like:

BEGIN;
LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE;
BEGIN;
CREATE TABLE "test" ("id" bigserial, "city" varchar(40), "temp_lo" integer, "temp_hi" integer, "prcp" float, "inserted_at" timestamp(0) NOT NULL, "updated_at" timestamp(0) NOT NULL, PRIMARY KEY ("id"));
INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ('20210718204657','2021-07-18 20:53:49');
COMMIT;
COMMIT;

When a migration fails, the transaction is rolled back and no changes are kept in the database. In most situations, these are great defaults.

Veteran database administrators may notice the database transactions (BEGIN/COMMIT) and wonder how to turn those off in situations where transactions could cause problems; such as when adding indexes concurrently; Ecto provides some options that can help with transactions and locks.  Let's explore some of those options next.

Migration Options

A typical migration has this structure (reminder: this guide is using Postgres; other adapters will vary):

BEGIN;
  LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE;
  BEGIN;
    -- after_begin callback
    -- my changes
    -- before_commit callback
    INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
  COMMIT;
COMMIT;

my_changes refers to the changes you specify in each of your migrations.

@disable_migration_lock

By default, Ecto acquires a lock on the "schema_migrations" table during the migration transaction:

BEGIN;
  -- ↓ THIS LOCK ↓
  LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE
  BEGIN;
    -- after_begin callback
    -- my changes
    -- before_commit callback
    INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
  COMMIT;
COMMIT;

You want this lock for most migrations because running multiple migrations simultaneously without this lock could have unpredictable results. In database transactions, any locks obtained inside the transaction are released when the transaction is committed, which then unblocks other transactions that touch the same records to proceed.

However, there are some scenarios where you don't want a lock. We'll explore these scenarios later on (for example, backfilling data and creating indexes).

You can skip this lock in Ecto by setting the module attribute @disable_migration_lock true in your migration. When the migration lock is disabled, the migration looks like this:

BEGIN;
  -- after_begin callback
  -- my changes
  -- before_commit callback
  INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
COMMIT;

@disable_ddl_transaction

By default, Ecto wraps your changes in a transaction:

BEGIN;
  LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE
  -- ↓ THIS TRANSACTION ↓
  BEGIN;
    -- after_begin callback
    -- my changes
    -- before_commit callback
    INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
  COMMIT;
  -- ↑ THIS TRANSACTION ↑
COMMIT;

This ensures that when failures occur during a migration, your database is not left in an incomplete or mangled state.

There are scenarios where you don't want a migration to run inside a transaction. Like when performing data migrations or when running commands such as CREATE INDEX CONCURRENTLY that can run in the background in the database after you issue the command and cannot be inside a transaction.

You can disable this transaction by setting the module attribute @disable_ddl_transaction true in your migration. The migration then looks like this:

BEGIN;
  LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE
  -- my changes
  INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
COMMIT;

Tip: For Postgres, when disabling transactions, you'll also want to disable the migration lock since that uses yet another transaction. When running these migrations in a multi-node environment, you'll need a process to ensure these migrations are only run once since there is no protection against multiple nodes running the same migration at the same exact time.

Disabling both the migration lock and the DDL transaction, your migration will be pretty simple:

-- my changes
INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);

Transaction Callbacks

In the examples above, you'll notice there are after_begin and before_commit hooks if the migration is occurring within a transaction:

BEGIN;
  -- after_begin hook  ← THIS HOOK
  -- my changes
  -- before_commit hook  ← AND THIS HOOK
  INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ($1,$2);
COMMIT;

You can use these hooks by defining after_begin/0 and before_commit/0 in your migration. A good use case for this is setting migration lock timeouts as safeguards (see later Safeguards section).

defmodule MyApp.Repo.Migrations.CreateTestTable do
  use Ecto.Migration

  def change do
    # ... my potentially long-locking migration
  end

  def after_begin do
    execute "SET lock_timeout TO '5s'", "SET lock_timeout TO '10s'"
  end
end

Be aware that these callbacks are not called when @disable_ddl_transaction is true because they rely on the transaction being present.

Inspecting Locks In a Query

Before we dive into safer migration practices, we should cover how to check if a migration could potentially block your application. In Postgres, there is a pg_locks table that we can query that reveals the locks in the system. Let's query that table alongside our changes from the migration, but return the locks so we can see what locks were obtained from the changes.

BEGIN;
  -- Put your actions in here. For example, validating a constraint
  ALTER TABLE addresses VALIDATE CONSTRAINT "my_table_locking_constraint";

  -- end your transaction with a SELECT on pg_locks so you can see the locks
  -- that occurred during the transaction
  SELECT locktype, relation::regclass, mode, transactionid AS tid, virtualtransaction AS vtid, pid, granted FROM pg_locks;
COMMIT;

The result from this SQL command should return the locks obtained during the database transaction. Let's see an example: We'll add a unique index without concurrency so we can see the locks it obtains:

BEGIN;
  LOCK TABLE "schema_migrations" IN SHARE UPDATE EXCLUSIVE MODE;
  -- we are going to squash the embedded transaction here for simplicity
  CREATE UNIQUE INDEX IF NOT EXISTS "weather_city_index" ON "weather" ("city");
  INSERT INTO "schema_migrations" ("version","inserted_at") VALUES ('20210718210952',NOW());
  SELECT locktype, relation::regclass, mode, transactionid AS tid, virtualtransaction AS vtid, pid, granted FROM pg_locks;
COMMIT;

--    locktype    |      relation      |           mode           |  tid   | vtid  | pid | granted
-- ---------------+--------------------+--------------------------+--------+-------+-----+---------
--  relation      | pg_locks           | AccessShareLock          |        | 2/321 | 253 | t
--  relation      | schema_migrations  | RowExclusiveLock         |        | 2/321 | 253 | t
--  virtualxid    |                    | ExclusiveLock            |        | 2/321 | 253 | t
--  relation      | weather_city_index | AccessExclusiveLock      |        | 2/321 | 253 | t
--  relation      | schema_migrations  | ShareUpdateExclusiveLock |        | 2/321 | 253 | t
--  transactionid |                    | ExclusiveLock            | 283863 | 2/321 | 253 | t
--  relation      | weather            | ShareLock                |        | 2/321 | 253 | t
-- (7 rows)

Let's go through each of these:

  1. relation | pg_locks | AccessShareLock - This is us querying the pg_locks table in the transaction so we can see which locks are taken. It has the weakest lock which only conflicts with Access Exclusive which should never happen on the internal pg_locks table itself.
  2. relation | schema_migrations | RowExclusiveLock - This is because we're inserting a row into the "schema_migrations" table. Reads are still allowed, but mutation on this table is blocked until the transaction is done.
  3. virtualxid | _ | ExlusiveLock - Querying pg_locks created a virtual transaction on the SELECT query. We can ignore this.
  4. relation | weather_city_index | AccessExclusiveLock - We're creating the index, so this new index will be completely locked to any reads and writes until this transaction is complete.
  5. relation | schema_migrations | ShareUpdateExclusiveLock - This lock is acquired by Ecto to ensure that only one mutable operation is happening on the table. This is what allows multiple nodes able to run migrations at the same time safely. Other processes can still read the schema_migrations table, but you cannot write to it.
  6. transactionid | _ | ExclusiveLock - This lock is on a transaction that is happening; in this case, it has an Exclusive Lock on itself; meaning that if another transaction occurring at the same time conflicts with this transaction, the other transaction will acquire a lock on this transaction so it knows when it's done. I call this "lockception". 🙂🤯
  7. relation | weather | ShareLock - Finally, the reason why we're here. Remember, we're creating a unique index on the "weather" table without concurrency. This lock is our red flag 🚩. Notice it acquires a ShareLock on the table. This means it blocks writes! That's not good if we deploy this and have processes or web requests that regularly write to this table. UPDATE, DELETE, and INSERT acquire a RowExclusiveLock which conflicts with the ShareLock.

To avoid this lock, we change the command to CREATE INDEX CONCURRENTLY ...; when using CONCURRENTLY, it prevents us from using database transactions which is unfortunate because now we cannot easily see the locks the command obtains. We know this will be safer however because CREATE INDEX CONCURRENTLY acquires a ShareUpdateExclusiveLock which does not conflict with RowExclusiveLock (See Reference Material).

This scenario is revisited later in Part 3 - Migration Recipes.

Safeguards in the database

It's a good idea to add safeguards so no developer on the team accidentally locks up the database for too long. Even if you know all about databases and locks, you might have a forgetful day and try to add an index non-concurrently and bring down production. Safeguards are good.

We can add one or more safeguards:

  1. Automatically cancel a statement if the lock is held for too long. There are two ways to do this:
    1. Apply to migrations. This can be done with a lock_timeout inside a transaction.
    2. Apply to any statements. This can be done by setting a lock_timeout on a Postgres role.
  2. Automatically cancel statements that take too long. This is broader than #1 because it includes any statement, not just locks.

Let's dive into these safeguards.

Add a lock_timeout

One safeguard we can add to migrations is a lock timeout. A lock timeout ensures a lock will not last more than n seconds. This way, when an unsafe migration sneaks in, it only locks tables to updates and writes (and possibly reads) for n seconds instead of indefinitely when the migration finishes.

From the Postgres docs:

Abort any statement that waits longer than the specified amount of time while attempting to acquire a lock on a table, index, row, or other database object. The time limit applies separately to each lock acquisition attempt. The limit applies both to explicit locking requests (such as LOCK TABLE, or SELECT FOR UPDATE without NOWAIT) and to implicitly-acquired locks. If this value is specified without units, it is taken as milliseconds. A value of zero (the default) disables the timeout.

Unlike statement_timeout, this timeout can only occur while waiting for locks. Note that if statement_timeout is nonzero, it is rather pointless to set lock_timeout to the same or larger value, since the statement timeout would always trigger first. If log_min_error_statement is set to ERROR or lower, the statement that timed out will be logged.

There are two ways to apply this lock:

  1. localized to the transaction
  2. default for the user/role

Let’s go through those options:

Transaction lock_timeout

In SQL:

SET lock_timeout to '5s';

Let's move that to a Ecto migration transaction callback.

You can set a lock timeout in every migration:

def after_begin do
  # execute/2 can be ran in both migration directions, up/down.
  # The first argument will be ran when migrating up.
  # The second argument will be ran when migrating down. You might give yourself
  # a couple extra seconds when rolling back.
  execute("SET lock_timeout TO '5s'", "SET lock_timeout TO '10s'")
end

But this can get tedious since you'll likely want this for every migration. Let's write a little macro to help with this boilerplate code.

In every migration, you'll notice that we use Ecto.Migration which inserts some code into your migration. Let's use this same idea to inject a boilerplate of our own and leverage an option to set a lock timeout. We define the after_begin callback to set the lock timeout.

defmodule MyApp.Migration do
  defmacro __using__(opts) do
    lock_timeout = Keyword.get(opts, :lock_timeout, [up: "5s", down: "10s"])

    quote do
      use Ecto.Migration

      if unquote(lock_timeout) do
        def after_begin do
          execute(
            "SET lock_timeout TO '#{Keyword.fetch!(unquote(lock_timeout), :up)}'",
            "SET lock_timeout TO '#{Keyword.fetch!(unquote(lock_timeout), :down)}'"
          )
        end
      end
    end
  end
end

And adjust our migration:

defmodule MyApp.Repo.Migrations.CreateTestTable do
-  use Ecto.Migration
+  use MyApp.Migration

  def change do
    # my changes
  end
end

Now the migrations will only be allowed to acquire locks up to 5 seconds when migrating up and 10 seconds when rolling back. Remember, these callbacks are not called when @disable_ddl_transaction is set to true.

You can override the lock timeout if needed by passing in options:

# disable the lock_timeout
use MyApp.Migration, lock_timeout: false

# or change the timeouts
use MyApp.Migration, lock_timeout: [up: "10s", down: "20s"]

Role-level lock_timeout

Alternatively, you can set a lock timeout for the user in all commands:

ALTER ROLE myuser SET lock_timeout = '10s';

If you have a different user that runs migrations, this could be a good option for that migration-specific Postgres user. The trade-off is that Elixir developers won't see this timeout as they write migrations and explore the call stack since database role settings are in the database which developers don't usually monitor.

Statement Timeout

Another way to ensure safety is to configure your Postgres database with statement timeouts. These timeouts apply to all statements, including migrations and the locks they obtain.

From Postgres docs:

Abort any statement that takes more than the specified amount of time. If log_min_error_statement is set to ERROR or lower, the statement that timed out will also be logged. If this value is specified without units, it is taken as milliseconds. A value of zero (the default) disables the timeout.

The timeout is measured from the time a command arrives at the server until it is completed by the server. If multiple SQL statements appear in a single simple-Query message, the timeout is applied to each statement separately. (PostgreSQL versions before 13 usually treated the timeout as applying to the whole query string.) In extended query protocol, the timeout starts running when any query-related message (Parse, Bind, Execute, Describe) arrives, and it is canceled by completion of an Execute or Sync message.

You can specify this configuration for the Postgres user. For example:

ALTER ROLE myuser SET statement_timeout = '10m';

Now any statement automatically times out if it runs for more than 10 minutes; opposed to running indefinitely. This can help if you accidentally run a query that runs the database CPU hot, slowing everything else down; now the unoptimized query will be limited to 10 minutes or else it will fail and be canceled.

Setting this statement_timeout requires discipline from the team; if there are runaway queries that fail (for example) at 10 minutes, an exception will likely occur somewhere. You will want to equip your application with sufficient logging, tracing, and reporting so you can replicate the query and the parameters it took to hit the timeout, and ultimately optimize the query. Without this discipline, you risk creating a culture that ignores exceptions.

Fly ❤️ Elixir

Fly is an awesome place to run your Elixir apps. Deploying, clustering, connecting Observer, and more are all supported!

Deploy your Elixir app today!

Where to next?

Next we dig into running your migrations in a Mix Release project!
